With rising manufacturing costs, pipe manufacturers are facing challenges on labor cost and labor shortages, LIANSU dedicated on how to make pipe production more simple and more efficient, LIANSU developed full range of hoses automatic coiler with online strapping.
Hereunder the projects cases we’d like to share is the major hose manufacturer in America,it eliminates manual offline inflation, semi-automatic coiling, strapping, packaging and unloading, improving efficiency and cutting labor costs.
Main Spec.
●Hose dia. range: Ø16 – Ø32
●Inner coiled ID: Ø160 mm
●External Coil OD: Ø320 – Ø600mm
●Coiling width: 175 – 320 mm
●Coiling speed: 20 m/min (coiling length > 25 m)
●Number of Straps: 3 straps per roll
Dual-station continuous operation enables non-stop hose winding
Adopting an independent dual-station coiling structure, the machine performs discharging and preparation at one station while the other is in operation, realizing uninterrupted coiling. In actual application, it greatly cuts manual intervention and meets the demand for long-hour continuous production.
Full-process automation, stable replacement of manual work
The machine realizes automatic operation of the whole process including coiling, coil changing, sealing, strapping and unloading. It automatically inflates the hose during coiling to keep it full and round, improving arrangement neatness and finished product appearance consistency. It greatly reduces reliance on labor and significantly enhances production stability.
On-site Operation Performance
●More stable coiling cycle and stronger continuous production capacity.
●Neater finished product arrangement and higher appearance consistency.
●Less manual involvement and lower labor intensity.
●Improved production continuity to meet high-volume order demands.
The Coiler realizes automatic online coiling and packaging. continuous stable operation boosts productivity and product quality, delivering a reliable automated solution for clients.
